Second-hand paper machine (Use)
Two high-value insulation/technical paper machines now available .
Explore our newly available special-purpose paper machines ready for dismantling and export.
Complete Production Line for Technical, Capacitor & Insulation Papers(Voith)1958
Contact us for the best Offer \ Price
Complete Production Line for Technical, Capacitor & Insulation Papers(Voith)1953
Contact us for the best Offer \ Price
Or talk to us immediately +49 176 44463658
Quantity:1
Description
Manufacturer: Voith
Year of Construction: 1958
This line underwent a comprehensive modernization in 2010, which included:
• Installation of a new headbox
• Refurbished suction roll
• Upgraded pick-up and first press section
• Enhanced wire section performance
• Extended dryer section
• Replacement of drive systems
Working width at Pope reel: 2160 mm
Working width after calender: 2120 mm
Maximum operating speed: 60–130 m/min
Production capacity: approx. 1,250 tons/year
Paper Grades Produced
This machine is designed for the manufacture of technical specialty papers used in electrical and industrial applications, including:
• Calendered capacitor papers
• Electrolytic papers made from kraft pulp
• Long-fiber kraft electrolytic papers
• Cable, transformer, and insulation papers
Basis weight range: 8.2 – 55 g/m²
Line Composition
The production system includes:
• Stock preparation and approach flow
• Complete paper machine from headbox to pope reel
• Vacuum system
• Krofta flotation unit
• Auxiliary systems
• Goebel slitter rewinder
Paper machine length: 36 m
Total system length: approx. 70 m
Additional Information
• Spare parts: supplied as available
• Technical documentation: provided where available
• Condition: machine shut down in January 2025, well maintained and in very good working order
Specifications
Manufacturer Voith
Model Fourdrinier
Year 1958
Condition UsedStock
Number MR0028
Location ****** NDA
Or talk to us immediately +49 176 44463658
Quantity:1
Description
Manufacturer: Voith
Year Built: 1953
This production line has undergone several major upgrades, the most significant being the 2010 overhaul, which included:
• Installation of a modernized headbox
• Refurbished suction roll
• Updated cleaner and screening systems
• Optimization of the wire section
• Extension of the dryer section
• Replacement of the drive units
Web width at pope reel: 1950 mm
Web width after calender: 1850 mm
Headbox pond width: approx. 2160 mm
Maximum operating speed: 60 – 150 m/min
Annual output capacity: approx. 1,600 tons
Paper Grades Produced
This machine is designed to manufacture various specialty technical papers, such as:
• Calendered capacitor papers
• Kraft-based electrolytic papers
• Long-fiber kraft electrolytic papers
• Cable, transformer, and insulating grades
Basis weight range: 13.5 – 40 g/m²
Machine Components Included
The line comes with:
• Stock preparation and approach flow system
• Complete paper machine from headbox through pope reel
• Vacuum system
• Krofta flotation deinking/clarification unit
• Auxiliary equipment and supporting systems
Paper machine length: approx. 36 m
Total installation length: approx. 70 m
Additional Details
• Spare parts: supplied as available
• Technical documentation: provided where available
• Operating status: taken out of production in January 2025, very well preserved
Specifications
Manufacturer Voith
Model Fourdrinier
Year 1953
Condition UsedStock
Number MR0029
Location ****** NDA
